| 出口压力 |
进口压力
PSIG(bar) |
流量
SCFH(m3/h(n))
CAPACITIES IN SCFH(m3/h(n)) OF 0.8 SPECIFIC GRAVITY
NATURAL GAS |
| 阀体内部口径 Inches(mm) |
1/4 x3/8
(64x9.5) |
1/2(12.7) |
3/4(19.1) |
7/8(22.2) |
1-3/16(30.2) |
1.0 to 3.25 psig
(69 to 224
mbar)
2 psig
(138
mbar)
±1%psia(bar)
T13593T0012
Light Blue |
5(0.34)
10(0.69)
15(1.0)
20(1.4) |
1020(27)
1550(42)
1920(51)
2240(60) |
3640(98)
5610(156)
7580(203)
8960(240) |
7440(199)
12040(323)
15990(429)
19250(516) |
8850(232)
14410(386)
18950(508)
24110(646) |
13560(363)
22570(605)
30760(824)
37410(1003) |
25(1.7)
30(2.1)
40(2.8)
50(3.4)
60(4.1) |
2570(69)
2890(77)
3530(95)
4180(112)
4820(129) |
10250(275)
11540(309)
14120(378)
16700(448)
19280(517) |
22030(590)
24800(665)
30350(813)
35890(962)
41440(1111) |
27110(727)
31110(834)
38100(1021)
44100(1182)
51090(1369) |
45330(1215)
51040(1368)
62450(1674)
73870(1980)
85290(2286) |
80(5.5)
100(6.9)
125(8.6)
150(10.3)
175(12.1) |
6110(164)
7400(198)
9020(242)
10630(285)
12240(328) |
24440(655)
29600(793)
36050(966)
42500(1139)
48950(1312) |
52540(1408)
63630(1705)
77500(2077)
91360(2448)
--------- |
65080(1744)
79060(2119)
96050(2574)
---------
--------- |
108120(2898)
----------
----------
----------
---------- |
3.2 to 6 psig
(224 to 414
mbar)
5 psig
(345
mbar)
±1%psia(bar)
T13671T0012
Orange |
10(0.69)
15(1.0)
20(1.4)
25(1.7) |
1390(37)
1870(50)
2240(60)
2570(69) |
5050(135)
7280(195)
8850(237)
10250(275) |
10350(277)
15150(406)
18640(500)
22030(590) |
12900(340)
17950(481)
22970(616)
27110(727) |
19030(510)
28530(765)
35820(960)
42530(1140) |
30(2.1)
40(2.8)
50(3.4)
60(4.1)
80(5.5) |
2890(77)
3530(95)
4180(112)
4820(129)
6110(164) |
11540(309)
14120(378)
16700(448)
19280(517)
24440(655) |
24800(665)
30350(813)
35890(952)
41440(1111)
52540(1408) |
31110(834)
38100(1021)
44100(1182)
519090(1369)
65080(1744) |
51040(1368)
62450(1674)
73870(1980)
85290(2286)
108120(2898) |
100(6.9)
125(8.6)
150(10.3)
175(12.1) |
7400(198)
9020(242)
10530(285)
12240(328) |
29600(793)
36050(966)
42500(1139)
48950(1312) |
63630(1705)
77500(2077)
91360(2448)
-------- |
79060(2119)
96050(2574)
---------
--------- |
----------
----------
----------
---------- |
6 to 16 psig
(0.41 to 1.10
bar)
10 psig
(0.69
bar)
±1%psia(bar)
T13600T0012
Red |
15(1.0)
20(1.4)
25(1.7)
30(2.1) |
1580(42)
2130(57)
2540(68)
2890(77) |
5690(152)
8210(220)
9930(266)
11540(309) |
11640(312)
17000(456)
20790(557)
24150(647) |
12640(339)
20380(546)
24570(658)
29540(792) |
21280(570)
31690(849)
39480(1058)
46550(1248) |
40(2.8)
50(3.4)
60(4.1)
80(5.5) |
3530(95)
4180(112)
4820(129)
6110(164) |
14120(378)
16700(448)
19280(517)
24440(655) |
30350(813)
35890(962)
41440(1111)
52540(1408) |
38100(1021)
44100(1182)
51090(1369)
65080(1744) |
62450(1674)
73870(1980)
85290(2266)
108120(2898) |
100(6.9)
125(8.6)
150(10.3)
175(12.1) |
7400(198)
9020(242)
10530(285)
12240(328) |
29600(793)
36050(966)
42500(1139)
48950(1312) |
63630(1705)
77500(2077)
91360(2448)
--------- |
79060(2119)
96050(2574)
---------
--------- |
---------
---------
---------
--------- |
