● THE CAPACITY OF OUR ELECTRIC WATERBATH VAPORIZERS RANGE FROM 30 KGS/HR TO 300KGS/HR.

● HEATERS AND AUTO-THERMOSTATS ARE EXPLOSION PROOF STRUCTURES. A d1G2 。

● WE USE SEAMLESS STAINLESS TUBES FOR THE HEATER. THE WATER TANK,LIQUID COILED TUBES,AND VAPOR TANK ARE STRICTLY ZINCGALVANIZED TREATED.THIS TREATMENT ASSURES OUR VAPORIZERS TO BECORROSION RESISTANT AND TO POSSESS A LONGER LIFE.

● OUR COMPANY INSISTS ON USING SEAMLESS TUBE AND SOCKETWELD FITTINGS TO ASSURE END-USERS' SAFETY. ALL OUR VAPORIZERS HAVE TO PASS A 30KGS/CM2 HIGH PRESSURE TEST.

● STAINLESS FLOAT VALVE PREVENTS LIQUID GAS FROM BEING CARRIED INTO THE OVEN THEOUGH THE PIPING.

● SPECIALLY DESIGNED LIQUID DRAIN VALVE CAN QUICKLY EXPEL THE ACCUMULATED LIQUED RESIDUE FROM THE VAPORIZER.

● SAFETY VALVE ON THE VAPOR SIDE CAN AUTOMATICALLY SHUT OFF AFTER RELEASING OVER-PRESSURE GAS.

● GLASS FIBER INSULATION OF 25MM IN THICKNESS KEEPS THE TEMPERATURE OF THE WATER TANK STEADY AND REDUCES THE CONSUMPTION OF ELECTRICITY.

● OUR VAPORIZERS PROVIDE YOU WITH AN INTEGRAL, COMPACT UNIT WHICH PRODUCES ADRY AND WARM VAPOR AND IS ABLE TO SUCCESSFULLY CONTROL INFINITE TURNDOWN.

● VAPORIZERS SHOULD BE INSTALLED:1.IN WINDY SURROUNDINGS. 2. 8 METERS AWAY FROM OVEN,ELECTRICAL WIRE OR SWITCHES AS WELL AS ANY NON-EXPLOSION FUNCTION OF ELECTRICAL APPARATUS. 3. ON A SOLID AND CONCRETE FOUNDATION.

● PLEASE CHECK IN ADVANCE THE FOLLOWING BEFORE USING: 1. THE WATER LEVEL IS BETWEEN THE HIGH-LOW INDICATOR ON THE LEVEL GAUGE. 2. THE TEMPERATURE HAS REACHED BETWEEN 70°-80℃.3. THE LIQUID AND VAPOR RESIDUE FROM THE DRAIN VALVE HAS BEEN RELEASED.

● CHANGE THE WATER AT LEAST EVERY TWO MONTHS.

● KEEP THE SWITCH OF THE SAFETY VALVE OPEN.
