XL-45 |
XL-50 |
XL-55 |
XL-65 |
XL-70 |
Dimensions
Diameter
Height |
20in.(508mm)
611/2
in.(1562mm) |
20in.(508mm)
645/8
in.(1641mm) |
20in.(508mm)
697/16
in.(1764mm) |
26in.(660mm)
591/2
in.(1511mm) 4 |
26in.(660mm)
631/4
in.(1607mm) |
Weight
Empty (Nominal)
5 caster Base
4 caster Base |
255lb.(116kg) |
270lb.(122kg) |
270lb.(122kg) |
375lb.(170kg)4 |
395lb.(179kg)
465lb.(211kg) |
Maximum Liquid
Capacity |
180Liters |
193Liters |
210Liters |
250Liters |
280Liters |
Usable Liquid Capacity |
169Liters |
181Liters |
200Liters |
240Liters |
265Liters |
Normal Evaporation Rate
% Capacityper day
Oxygen
Nitrogen
Argon
Carbon Dioxide
Nitrous Oxide |
1.2%
1.9%
1.2%
N/A
N/A |
1.1%
1.8%
1.1%
N/A
N/A |
1.1%
1.7%
1.1%
N/A
N/A |
0.9%
1.4%
0.9%
N/A
N/A |
1.0%
1.6%
1.0%
N/A
N/A |
Gas Withdrawal Rrate2
@ NTP(STP)
Oxygen
Nitrogen
Argon
Carbon Dioxide
Nitrous Oxide
|
350cfh(9.2cu.m/h)
350cfh(9.2cu.m/h)
350cfh(9.2cu.m/h)
N/A
N/A
|
350cfh(9.2cu.m/h)
350cfh(9.2cu.m/h) 350cfh(9.2cu.m/h)
N/A
N/A
|
350cfh(9.2cu.m/h)
350cfh(9.2cu.m/h) 350cfh(9.2cu.m/h)
N/A
N/A
|
350cfh(9.2cu.m/h)
350cfh(9.2cu.m/h) 350cfh(9.2cu.m/h)
N/A
N/A
|
350cfh(9.2cu.m/h)
350cfh(9.2cu.m/h) 350cfh(9.2cu.m/h)
N/A
N/A
|
Dual Pressure Building/Economizer Regulator3
Pressure Building Setting
Economizer Setting
|
125psig
(8.6bar/862kpa)
145psig
(10bar/1000kpa) |
125psig
(8.6bar/862kpa)
145psig
(10bar/1000kpa)
|
125psig
(8.6bar/862kpa)
145psig
(10bar/1000kpa)
|
125psig
(8.6bar/862kpa)
145psig
(10bar/1000kpa) |
125psig
(8.6bar/862kpa)
145psig
(10bar/1000kpa) |
Design Specification
TC N/A
DOT
Rated DOT service Pressure
|
4LM
4L
200psig
(13.8bar/1379kpa) |
4LM
4L
200psig
(13.8bar/1379kpa) |
4LM
4L
200psig
(13.8bar/1379kpa) |
4LM
4L
200psig
(13.8bar/1379kpa) |
4LM
4L
200psig
(13.8bar/1379kpa) |
Safety Devices
Pressure Relief Valve
Inner Container Bursting Disc
|
230psig (16bar/1586kpa) 360psig (24.8bar/2482kpa) |
230psig (16bar/1586kpa) 360psig (24.8bar/2482kpa) |
230psig (16bar/1586kpa) 360psig (24.8bar/2482kpa) |
230psig (16bar/1586kpa) 360psig (24.8bar/2482kpa) |
230psig (16bar/1586kpa) 360psig (24.8bar/2482kpa) |
Weight of Contents
Based on DOT Rated
Service Pressure Oxygen
Nitrogen
Argon
Carbon Dioxide
Nitrous Oxide
|
388lb.(176kg) 273lb.(124kg) 471lb.(214kg)
N/A
N/A
|
416lb.(189kg) 293lb.(133kg) 505lb.(229kg)
N/A
N/A |
454lb.(206kg) 319lb.(145kg) 551lb.(250kg)
N/A
N/A |
539lb.(244kg) 380lb.(172kg) 655lb.(297kg)
N/A
N/A |
606lb.(275kg) 426lb.(193kg) 735lb.(333kg)
N/A
N/A |
Gaseous Capacity
Based on DOTrated Service
Pressure@NTP(STP)
Oxygen
Nitrogen
Argon
Carbon Dioxide
Nitrous Oxide
|
4688cu.ft.(123cu.m) 3771cu.ft.(99cu.m) 4558cu.ft.(120cu.m) N/A N/A |
5025cu.ft.(132cu.m) 4043cu.ft.(106cu.m) 4884cu.ft.(128cu.m) N/A N/A |
5484cu.ft.(144cu.m) 4402cu.ft.(116cu.m) 5331cu.ft.(140cu.m) N/A
N/A |
6511cu.ft.(171cu.m) 5244cu.ft.(139cu.m) 6335cu.ft.(166cu.m) N/A N/A |
7320cu.ft.(207cu.m) 5879cu.ft.(166cu.m) 7112cu.ft.(201cu.m) N/A N/A |
